Seamless steel tubes for pressure purposes
· EN 10216-1 Non-alloy steel tubes with specified room temperature properties
· EN 10216-2 Non alloy and alloy steel tubes with specified elevated temperature properties
· EN 10216-3 Alloy fine grain steel tubes
· EN 10216-4 Non-alloy and alloy steel tubes with specified low temperature properties
· EN 10216-5 Stainless steel tubes
DIN EN 10216-1
Seamless steel tubes for pressure purposes–Technical delivery conditions-Part 1: Non-alloy steel tubes with specified room temperature properties
Specifies the technical delivery conditions for two qualities, T1 and T2, of seamless tubes of circular cross section, with specified room temperature properties, made of non-alloy quality steel…
DIN EN 10216-2
Seamless steel tubes for pressure purposes–Technical delivery conditions – Part 2: Non alloy and alloy steel tubes with specified elevated temperature properties; German version EN 10216-2:2002+A2:2007
The document specifies the technical delivery conditions in two test categories for seamless tubes of circular cross section, with specified elevated temperature properties, made of non-alloy and alloy steel.
DIN EN 10216-3
Seamless steel tubes for pressure purposes-Technical delivery conditions – Part 3: Alloy fine grain steel tubes
Specifies the technical delivery conditions in two categories for seamless tubes of circular cross section, made of weldable alloy fine grain steel
DIN EN 10216-4
Seamless steel tubes for pressure purposes –Technical delivery conditions -Part 4: Non-alloy and alloy steel tubes with specified low temperature properties
Specifies the technical delivery conditionsin two categories for seamless tubes of circular crossection, made with specified low temperature properties, made of non-alloy and alloy steel…
DIN EN 10216-5
Seamless steel tubes for pressure purposes–Technical delivery conditions-Part 5: Stainless steel tubes; German version EN 10216-5:2004, Corrigendum to DIN EN 10216-5:2004-11; German version EN 10216-5:2004/AC:2008
This Part of this European Standard specifies the technical delivery conditions in two test categories for seamless tubes of circular cross-section made of austenitic (including creep resisting steels) and austenitic-ferritic stainless steel which are applied for pressure and corrosion resisting purposes at room temperature, at low temperatures or at elevated temperatures. It is important that the purchaser, at the time of enquiry and order, takes in account the requirements of the relevant national legal regulations for the intended application.
Read more:
DIN: Deutsche Industrie Normen (=German Industry Standard)
Ordering Information
Orders for material under this specification should include the following, as required, to describe the desired material adequately:
| Quantity | Feet, meters, or number of lengths |
Name of material | Seamless Alloy Steel Pipe |
Grade | STANDARD AND STEEL GRADE |
Manufacture | Hot-finished or cold-drawn |
Size using one of the following: | |
NPS and Schedule Number | |
Outside Diameter and Nominal Wall Thickness | |
Length | Specific or Random |
End Finish | |
Size (mm) we can supply:
Hot-rolled: O.D.: 51-508; W.T.:7∼60; L: max 16000
Cold-drawn: O.D.: 10-50; W.T.:2∼10; L: max 16000
Hot-expanded：O.D.: 325-1020; W.T.:6∼50; L: max 12000 and other specifications in accordance with customer requirements.
Packing:
Beveled/black painting/ plastic caps/ in bundles/ steel strips/ wooden protection
Inspection and Test:
Chemical Composition Inspection, Mechanical Properties Test(Tensile Strength, Yield Strength,Elongation, Flaring, Flattening, Bending, Hardness, Impact Test), Surface and Dimension Test, Nodestructive Test, Hydrostatic Test.
Surface Treatment:
Oil-dip, Varnish, Passivation, Phosphating, Shot Blasting, Epoxy & Fbe Coating Painting as requested.
