GB Standard Alloy Round Bars

Next Inquire Now

Specifications

· Grade: Alloy steel

· Standard: AISI, ASTM, BS, DIN, GB, JIS

· OD：10-500mm

· Thickness: Max:800mm

· Width: 205mm~2300mm

· Length: 1000mm~6000mm

· Place of Origin: China (Mainland)

· Model Number: 1.7220 / SCM430 / 30CrMo4 / 4130 ; 4140/42CrMo4/1.7225; En24 34CrNiMo6 1.6582 4340.

· Application: Mould steel

· Technique: Forged

· Special Use: Mold Steel ,Statically and dynamically stressed components for vehicles, engines and machines. For parts of larger cross-sections, crankshafts, gears.

· Shape: Round bars/Flat bar/Plate

· Technology: Hot Rolled/Forged/Clod Draw

· Heat treatment: Annealing/Q+T

· Surface treatment:Black/Peeling/Polishing/Machined

· Delivery condition: Hot rolled or forged/ Peeled or black surface/annealed or QT

· Customer's logo: Available

· Test: SGS/UT100%/Elements testing

· Certificate: ISO/Mill certificate

· Experience: Ten years manufacturer experience

Chemical composition

Standard Number		C	Mn	Si	Cr	Mo	P	S	Ni
GB	42CrMo	0.38~0.45	0.50~0.8	0.17~0.37	0.9~1.2	0.15~0.25	≤0.035	≤0.035	≤0.3
AISI	4140	0.40~0.45	0.75~1.0	0.15~0.35	0.8~1.1	0.15~0.25	≤0.035	≤0.040
GB	40CrNiMoA	0.37~0.44	0.17~0.37	0.50~0.80	0.6~0.9	0.15~0.25	≤0.035	≤0.035	1.25~1.65
AISI	4340	0.38~0.43	0.15~0.35	0.60~0.80	0.7~0.9	0.20~0.30	≤0.035	≤0.040	1.65~2.00
